Compact FWI Series RF Chip Wire Wound Inductors

FWI Series SMD Chip Wire Wound Inductors | FWI0603

Features

  • ROHS, Halogen and REACH Compliance
  • Ferrite core wire wound construction.
  • High Reliability due to wire wound-type construction.
  • Small footprint as well as low profile.
  • Application for DC power line.
  • The products contain no lead and also support lead-free soldering.

Applications

  • Microtelevisions, Liquid crystal televisions.
  • Car radios and car stereos.
  • Television tuners, Radio, and other electronic devices.
  • Video cameras, portable VCRs, and mobile telephones.

Zxcompo is a trusted manufacturer of ceramic chip inductors. Contact us to get samples: sales@ZXcompo.com

Minimum order quantity: 1 piece
Supply capacity: 1,000,000 pieces per month

  • Dimensions
  • Downloads
  • The SMD high-performance surface mount common mode choke is available in various industry-standard dimensions and constructions. The HWI Series of wire-wound common mode chokes is designed to eliminate common-mode noise from DC lines over a broad range of frequencies. The wire-wound common mode choke has a 1:1 impedance ratio or balun structure with different turn ratios. It can work in high frequencies up to GHz with a standard insertion loss of only 0.8 dB, making it suitable for USB 2.0, HDMI 2.0, USB 3.0, IEEE 1394, and LVDS applications.

    Zxcompo Leadtime:
    Zxcompo’s standard delivery time is 1~2 weeks, and fast delivery plans are available in urgent cases. We can dispatch goods within 10 or 20 working days for specific product ranges. This offers customers reliable quality and stable (short) delivery dates (in urgent cases, the delivery date could be 1 week only)

    Zxcompo Customization:
    In addition to the standard features of our family of specifications, Zxcompo offers low minimum order quantities (MOQs), tighter tolerances, and custom products for different inductance and frequency applications. With our team of engineers’ deep background in the ferrite powder field, we can modify the core powder to design and produce the most suitable product to meet our customers’ applications.

    Notes:
    1. Current that causes a 40°C temperature rise at 25°C ambient. This information is for reference only and does not represent absolute maximum ratings.
    2. Maximum current that can be applied at 85°C.
    3. Maximum current that can be applied at 125°C.

    Remark: The design is as per the customer’s request specification.

    📨*Send us your project requirements!*📨



    Shape and Dimensions:


    Our team of engineers has 15 years of experience in this field. We design and produce the most suitable products for our customers to meet their applications. Contact email: sales@ZXcompo.com.

    Zxcompo - RF Chip Wire Wound Inductors

    Part Number Dimensions (mm)
    L G H
    FWI0603 2.10 0.30 1.30
    FWI0805 2.70 0.55 2.10
    FWI1008 3.50 0.70 3.20
    FWI1210 4.40 1.00 3.50
    FWI1812 5.50 1.90 4.00

    Parameters of FWI Series Inductor


    The following are the parameters of this series of inductors produced by Zxcompo. If you need these products, you are welcome to contact us. Contact email: sales@ZXcompo.com.


    Title

    Size(mm)

    Inductance(uH)

    Qmin

    SRF(MHz)

    Irms(mA)

    DCR Max(Ω)

    Action

    1.8x 1.2 x 1.1

    1.0uh

    10

    240

    300

    0.75

    1.8x 1.2 x 1.1

    2.2uh

    10

    150

    250

    0.9

    1.8x 1.2 x 1.1

    3.3uh

    10

    120

    220

    1.46

    1.8x 1.2 x 1.1

    4.7uh

    8

    90

    190

    1.9

    1.8x 1.2 x 1.1

    6.8uh

    6

    65

    150

    2.6

    1.8x 1.2 x 1.1

    8.2uh

    6

    50

    130

    4.0

    1.8x 1.2 x 1.1

    10.0

    5

    40

    100

    5.5

    Product Identification:


    FWI 0603 -4R7 K S T
    • Series name.
    • Dimensions L×W.
    • Inductance: R47-0.47uH  4R7-4.7uH  470-47uH  471-470uH.
    • Tolerance: J:±5%  K: ±10%  M: ±20%
    • Terminal: S-Sn terminal
    • Package: B: by bulk   T: Tape and Reel.
  • FWI Series Wire Wound Inductors

    FWI Series Wire Wound inductors

    Detailed pieces of information including inductance, tolerance, rated current and DCR.
