ZXcompo High Current Toroidal Fixed Inductors ZXcompo Through Hole High Current Toroidal Power Choke T Series Toroidal Inductor

TII Series Toroidal Coil Inductors

Features

  • High staturation current.
  • Offering much lower losses, with energy storange capability high.
  • Toroidal distributed gap makes less leakage of magnetic flux.
  • Useful in a wide variety of power conversion and line filter applications.

Applications

  • Automotive
  • Output chokes.
  • Switching mode power supplies.
  • SCR and Triac Controls.
  • EMI filters, loading coils, and Q filters.

Minimum order quantity: 1 pieces
Supply capacity: 1,000,000 pieces per month

  • Dimensions
  • Downloads
  • A toroidal chokes inductor is an electronic component that is designed to filter or suppress common mode noise in electrical circuits by providing a high impedance path to the common mode current while allowing the desired differential mode current to pass through with minimal impedance.
    The applications for this toroidal choke inductor are for power adapters, DC-DC converters or AC-DC converters for example. The insulation between two winding normally will be 1.5KV at minimum. The core used on the pin type of toroidal choke inductor will be manganese zinc and nanocrystal core to achieve higher inductance value and lower DC resistance. Customer’s specifications are welcome.

    Zxcompo Leadtime:
    Zxcompo’s standard delivery time is 1~2 weeks, and fast delivery plans are available in urgent cases. We can dispatch goods within 10 or 20 working days for specific product ranges. This offers customers reliable quality and stable (short) delivery dates (in urgent cases, the delivery date could be 1 week only)

    Zxcompo Customization:
    Except for the standard characteristic of our series specification, ZXcompo Electronics also offers a customization product with low minimum order quantity (MOQ), tighter tolerance, and different inductance and frequency applications.

    Remark: The design is as per the customer’s request specification.

    📨*Send us your project requirements!*📨

    Shape and Dimensions:


    Our team of engineers has 15 years of experience in this field. We design and produce the most suitable products for our customers to meet their applications. Contact email: sales@ZXcompo.com.



    Parameters of TII Series Inductor


    The following are the parameters of this series of inductors produced by Zxcompo. If you need these products, you are welcome to contact us. Contact email: sales@ZXcompo.com.


    Title

    Size(mm)

    Inductance (uH)

    DCR Max (Ω)

    Irms Max (mA)

    Action

    22 x 12

    20

    0.040

    700

    22 x 12

    8.2

    0.040

    900

    20 x 10

    1.2

    0.020

    800

    20 x 10

    22

    0.045

    900

    22 x 12

    200

    0.010

    900

    22 x 12

    43

    0.080

    700

    T Series Toroidal Choke Coil Inductors Factory

    T Series Toroidal Choke Coil Inductor Material chapter

    Product Identification:


    T II 30 26 2R2 M
    • Series name.
    • Product symbol (I、H、II、HH).
    • Magnetic core specification.
    • Material No.
    • Inductance: R47-0.47uH  4R7-4.7uH  470-47uH.
    • Tolerance:  K: ±10%  M: ±20%  N: ±30%  .
  • ZXcompo High Current Toroidal Fixed Inductors

    TII Series Toroidal Coil Inductors

    Detailed informations including inductance, tolerance, rated current and DCR.
