NR Series Magnetic SMD Power Inductor | NR6045

A fully automated winding/soldering/testing and packing machine produces this miniature wire wound SMD power inductor. 100% check before each shipment, the testing included the characteristic inductance value, DC resistance, Isat current and layer isolation.
Inductors, also called coils or reactors, are electrical components that resist changes in electric current passing through them. It consists of a conductor such as a wire, wound into a coil. When the electric current changes, the magnetic field in the coil induces a voltage, opposing a change in current.

Zxcompo Leadtime:
Zxcompo’s standard delivery time is 1~2 weeks, and fast delivery plans are available in urgent cases. For specific product ranges, we can dispatch goods within 10 or 20 working days. This offers customers reliable quality and stable (short) delivery dates (in urgent cases, the delivery date could be 1 week only)

Zxcompo Customization:
In addition to the standard features of our family of specifications, Zxcompo offers low minimum order quantities (MOQs), tighter tolerances, and custom products for different inductance and frequency applications. With our team of engineers’ deep background in the ferrite powder field, we can modify the core powder to design and produce the most suitable product to meet our customers’ applications.
Whether your design targets power supplies, filtering circuits, or specialized applications, our custom semi-shielded SMD inductors can be meticulously optimized to excel within your precise field of application. If your PCB layout calls for a particular size to fit seamlessly, rest assured, we’ve got you covered. Our expertise allows us to customize the dimensions, ensuring a perfect integration with your design.

Remark: The design is as per the customer’s request specification.

📨*Send us your project requirements!*📨

Shape and Dimensions:

Our team of engineers has 15 years of experience in this field. We design and produce the most suitable products for our customers to meet their applications. Contact email: sales@ZXcompo.com.

Parameters of NR Series Inductor

The following are the parameters of this series of inductors produced by Zxcompo. If you need these products, welcome to contact us. Contact email: sales@ZXcompo.com.

Image	Title	Size(mm)	Inductance(uH)	Isat(mA)	Irms(mA)	DCR Max(Ω)	Action
	NR6045-1R0	6.0x 6.0 x 4.5	1.0	9850	5140	0.013	Details label Inquiry label
	NR6045-4R7	6.0x 6.0 x 4.5	4.7	4970	3300	0.034	Details label Inquiry label
	NR6045-150	6.0x 6.0 x 4.5	15	2500	2050	0.088	Details label Inquiry label
	NR6045-470	6.0x 6.0 x 4.5	47	1400	1200	0.26	Details label Inquiry label
	NR6045-101	6.0x 6.0 x 4.5	100	950	800	0.563	Details label Inquiry label
	NR6045-471	6.0x 6.0 x 4.5	470	500	420	3.25	Details label Inquiry label
	NR6045-102	6.0x 6.0 x 4.5	1000	300	300	5.83	Details label Inquiry label

Power Inductor Product Display

Product Identification:

• Series name.
• Dimensions D×T.
• Inductance: R33-0.33uH 3R3-3.3uH 100-10uH.
• Tolerance: J:±5% K: ±10% M: ±20%.
