CMW Series SMD Wire Wound Common Mode Inductors | CMW3216

Remark: Design as Customer’s request specification.

SHAPE AND DIMENSIONS

Zxcompo Electronics offer an extensive range of wirewound inductors designed to meet the diverse needs of your electronic projects. Among our offerings, we proudly present the Ferrite Core Wirewound Inductors, a powerful solution for various applications. Using Ferrite Core Wirewound Inductors can significantly reduce interference, ensuring cleaner signals and enhanced circuit performance. And wire-wound inductor with ferrite core provide a broad operating frequency range, making them versatile for applications spanning low to high frequencies. This flexibility accommodates various signal and power requirements.

Zxcompo Leadtime:
Zxcompo’s standard delivery time is 1~2 weeks, and in urgent cases, fast delivery plans are available. For specific product ranges, we can dispatch goods within 10 or 20 working days. This offer customer reliable quality and stable (short) delivery date (urgent case, the delivery date could be 1 weeks only)

Zxcompo Customization:
Some applications are magnetically sensitive, Zxcompo also provides non-ferrous cores products, such as ceramic or air-coil material. This will give you the low profile, high Q factor, and SRF (self-resonant frequency) value. The SMT miniature wire-wound inductors from Zxcompo have reliable quality due to the highly automated process. All of the products will be checked by the fully automated machine to reach our goal; zero defects. Furthermore, except for the standard part, a customized item is suitable for us.
In addition to the standard features of our family of specifications, Zxcompo offers low minimum order quantities (MOQs), tighter tolerances, and custom products for different inductance and frequency applications. With our team of engineers’ deep background in the ferrite powder field, we can modify the core powder to design and produce the most suitable product to meet our customers’ applications.

Image	Title	Size(mm)	Impenance(Ω)	Irms(mA)	DCR Max(Ω)	Withstand Voltage(V)	Insulation Resistance Min（mΩ）	Action
	CMW3216-90WCM	3.2x 1.6 x 1.6	90	400	0.3	50	10	Details label Inquiry label
	CMW3216-220WCM	3.2x 1.6 x 1.6	220	310	0.45	50	10	Details label Inquiry label
	CMW3216-370WCM	3.2x 1.6 x 1.6	370	300	0.5	50	10	Details label Inquiry label
	CMW3216-600WCM	3.2x 1.6 x 1.6	600	260	0.8	50	10	Details label Inquiry label
	CMW3216-1000WCM	3.2x 1.6 x 1.6	1000	230	1.0	50	10	Details label Inquiry label
	CMW3216-1400WCM	3.2x 1.6 x 1.6	1400	220	1.0	50	10	Details label Inquiry label
	CMW3216-2200WCM	3.2x 1.6 x 1.6	2200	200	1.2	50	10	Details label Inquiry label

PRODUCT IDENTIFICATION

• Series name.
• Dimensions L×W
• Impenance: 100-10Ω   161-160Ω .
• Type: D-Unshielded  T-Shielded.
• Circuit Number: 2-2 cicuit line.
