RID Series Radial Inductors

220uH 0.16Amps Plugable Radial Inductors

Features

  • Inductance Range(L): 220 µH
  • DC Resistance Max: 0.25 Ω
  • Rated Current Max: 110 mA
  • Core Material: Ferrite

Applications

  • Efficiency and saturation.
  • OA equipment choke.
  • High current low impedance.
  • Power supplies, DC/DC converters.
  • Switches, switching power supply for small and medium voltage.

Minimum order quantity: 1 piece
Supply capacity: 1,000,000 pieces per month

  • Dimensions
  • Downloads
  • Zxcompo also provides the clip-on ring core which utilizes the Mn-Zn core. They are also suitable for automotive applications. Our high-current radial led and toroid inductors are magnetically shielded to eliminate EMI and handle high currents in industrial and commercial environments. Various kinds of radial inductors from Zxcompo like magnetically shielded circuit design, winding cover by magnetic ring core. The through-hole power inductor features a small size, high Q value, low cost, high self-resonance frequency, high availability of a large current, small magnetic flux leakage, and large inductance value.

    Zxcompo Leadtime:
    Zxcompo’s standard delivery time is 1~2 weeks, and in urgent cases, fast delivery plans are available. For specific product ranges, we can dispatch goods within 10 or 20 working days. This offers customers reliable quality and stable (short) delivery dates (in urgent cases, the delivery date could be 1 week only)

    Zxcompo Customization:
    In addition to the standard features of our family of specifications, Zxcompo offers low minimum order quantities (MOQs), tighter tolerances, and custom products for different inductance and frequency applications. With our team of engineers’ deep background in the ferrite powder field, we can modify the core powder to design and produce the most suitable product to meet our customers’ applications.

    Remark: The design is as per the customer’s request specification.

    📨*Send us your project requirements!*📨

    Parameters of Radial Inductors:


    The following are the parameters of this series of inductors produced by Zxcompo. If you need these products, welcome to contact us. Contact email: sales@ZXcompo.com.

    Construction

    Size(mm)

    Inductance(uH)

    Tolerance

    Test Frequency
    (MHz/V)

    Isat(A)

    Irms(A)

    DCR(Ω)

    Shielded Inductor

    11.0x 9.5

    220

    M

    100Mhz/250V

    0.16

    0.16

    0.115

    Shape and Dimensions:


    Our team of engineers has 15 years of experience in this field. We design and produce the most suitable products for our customers to meet their applications. Contact email: sales@ZXcompo.com.

    RID Series Shielded Radial Choke Inductors _ Zxcompo

    RID Series Shielded Radial Choke Inductor RID Series Shielded Radial Choke Inductors _ ZXcompo Factory

    Product Identification:


    RID 0606 4R7 M
    • Radial inductor Series name.
    • Leaded inductor Dimensions D×L.
    • Inductance: R47-0.47uH 4R7-4.7uH 470-47uH.
    • Tolerance: K: ±10% M: ±20%.
  • Through Hole Power Inductor

    RID Series Radial Inductors

    Detailed informations including inductance, tolerance, rated current and DCR.
