RF Inductors

2.2nH 0.75A RF Ceramic 0402 Inductors

Features

  • ROHS and REACH compliant.
  • Inductance Range: 2.2 µH
  • DC Resistance: 0.10 Ω
  • Rated DC Current: 750 mA
  • Core Material: Ferrite & Ceramic
  • Material: Copper Wire

Applications

  • RF products for cellular phones.
  • GPS receiver, base station and Repeater.
  • Wireless LAN/Mouse/keyboard/earphone.
  • Remote control and Security system.

Minimum order quantity: 1 piece
Supply capacity: 1,000,000 pieces per month

  • Dimensions
  • Downloads
  • The miniature SMD wire-wound inductor is a type of inductor where the winding wire is wrapped around a core without magnetic shielding. On the other hand, the miniature SMD chip inductor is assembled using fully automated processes. Both types of inductors serve the same purpose in electronic circuits, particularly in applications with limited space, such as power supplies, DC-DC converters, and other electronic circuits.
    The type of miniature wire-wound inductor is suitable for the tuner (of circuits), and filter/amplification circuits because the product has high Q factors, high SRF (self-resonant frequency), and tight tolerance (2% available). Ceramic body and wire wound construction provide high SRFs. The product is RoHS, REACH, and Halogen-free compliance.

    Zxcompo Leadtime:
    Zxcompo’s standard delivery time is 1~2 weeks, and fast delivery plans are available in urgent cases. We can dispatch goods within 10 or 20 working days for specific product ranges. This offers customers reliable quality and stable (short) delivery dates (in urgent cases, the delivery date could be 1 week only)

    Zxcompo Customization:
    In addition to the standard features of our family of specifications, Zxcompo offers low minimum order quantities (MOQs), tighter tolerances, and custom products for different inductance and frequency applications. With our team of engineers’ deep background in the ferrite powder field, we can modify the core powder to design and produce the most suitable product to meet our customers’ applications.

    Notes:
    1. Current that causes a 40°C temperature rise at 25°C ambient. This information is for reference only and does not represent absolute maximum ratings.
    2. Maximum current that can be applied at 85°C.
    3. Maximum current that can be applied at 125°C.

    Remark: The design is as per the customer’s request specification.

    📨*Send us your project requirements!*📨

    Parameters of HWI Series Inductor


    The following are the parameters of this series of inductors produced by Zxcompo. If you need these products, you are welcome to contact us. Contact email: sales@ZXcompo.com.

    Construction

    Size(mm)

    Inductance(nH)

    Impedance tolerance

    Test Frequency
    (MHz)

    Qmin

    Irms(mA)

    DCR(Ω)

    Unshielded Inductor

    1.19x 0.66x 0.66

    2.2

    ±25%

    100

    15

    0.75

    0.10

    Shape and Dimensions:


    Our team of engineers has 15 years of experience in this field. We design and produce the most suitable products for our customers to meet their applications. Contact email: sales@ZXcompo.com.

    Ceramic Inductors SHAPE AND DIMENSIONS

    Part Number Dimensions (mm)
    E D F
    HWI0402 3.50 1.35 3.50
    HWI0603 3.50 1.35 3.50
    HWI1008 4.20 1.50 4.50
    HWI1210 5.30 1.90 5.30

    HWI Series Wire Wound Chip 0402 Ceramic Inductors (1) HWI Series Wire Wound Chip Ceramic Inductors 800x800

    Product Identification:


    HWI 0402 -068N K G T
    • Series name.1
    • Dimensions L×W2
    • Inductance: 6N8-6.8nH  068N-68uH  R68-680nH .3
    • Tolerance: J:±5%  K: ±10%  M: ±20%.4
    • Terminal: S-Sn terminal  G-Gold terminal.5
    • Package: B:by bulk   T: Tape and Reel.
  • RF Inductors

    HWI Series Wire Wound Chip Ceramic Inductors

    Detailed informations including inductance, tolerance, rated current and DCR.
