ZXcompo Wirewound Toroidal Power Inductor

180uH 0.5A Toroidal Common Mode Choke

Features

Inductance Range(L): 180 µH
DC Resistance: 0.250 Ω
Rated Current Max: 500 mA
Core Material: Iron Dust
High saturation current.
ROHS, Halogen and REACH Compliance.

Applications

Automotive
Output chokes.
Switching mode power supplies.
SCR and Triac Controls.
EMI filters, loading coils, and Q filters.

Minimum order quantity: 1 piece
Supply capacity: 1,000,000 pieces per month

GET A QUOTATION

Dimensions
Downloads

A toroidal chokes inductor is an electronic component that is designed to filter or suppress common mode noise in electrical circuits by providing a high impedance path to the common mode current while allowing the desired differential mode current to pass through with minimal impedance.
The applications for this toroidal choke inductor are for power adapters, DC-DC converters, or AC-DC converters for example. The insulation between two winding normally will be 1.5KV at minimum. The core used on the pin type of toroidal choke inductor will be manganese zinc and nanocrystal core to achieve higher inductance value and lower DC resistance. Customer’s specifications are welcome.

Zxcompo Leadtime:
Zxcompo’s standard delivery time is 1~2 weeks, and fast delivery plans are available in urgent cases. We can dispatch goods for specific product ranges within 10 or 20 working days. This offers customers reliable quality and stable (short) delivery dates (in urgent cases, the delivery date could be 1 week only)

Zxcompo Customization:
In addition to the standard features of our family of specifications, Zxcompo offers low minimum order quantities (MOQs), tighter tolerances, and custom products for different inductance and frequency applications. With our team of engineers’ deep background in the ferrite powder field, we can modify the core powder to design and produce the most suitable product to meet our customers’ applications.
Whether your design targets power supplies, filtering circuits, or specialized applications, our custom semi-shielded SMD inductors can be meticulously optimized to excel within your precise field of application. If your PCB layout calls for a particular size to fit seamlessly, rest assured, we’ve got you covered. Our expertise allows us to customize the dimensions, ensuring a perfect integration with your design.

Remark: The design is as per the customer’s request specification.

**📨Send us your project requirements!📨**

Parameters of THHB Series Inductor

The following are the parameters of this series of inductors produced by Zxcompo. If you need these products, you are welcome to contact us. Contact email: sales@ZXcompo.com.

Construction	Size(mm)	Inductance(uH)	Inductance Tolerance	Test Frequency （MHz）	Isat(A)	Irms(A)	DCR(Ω)
Unshielded Inductor	21 x 12	180	±20%	0.001	1.0	0.5	0.250

Shape and Dimensions:

Our team of engineers has 15 years of experience in this field. We design and produce the most suitable products for our customers to meet their applications. Contact email: sales@ZXcompo.com.
